BaBar SVT Pictures
The pictures below were generated in the Bogus SVT simulation ("Bogus" stands for BaBar Object-oriented Geant4-based Unified Simulation). Click on the picture to get a postscript version (it should fit the 8.5"x11" paper size). Larger gif files are also available here.The work is not yet complete -- you will notice a few detector elements missing; I will try to keep this page up to date with the project. Enjoy!
(Comments or questions should be directed to Natalia Kuznetsova natalia@charm.physics.ucsb.edu)
Support cones:
Support cones and cooling rings:
Silicon wafers and hybrids:
Hybrids and support cones:
Space frame:
SVT in all its glory:
You can see some of the electronics (IC's), as well as Berg connectors and bushings, on the hybrids on these pictures:
